Skar Audio engineered the SDR-1X15D2 single 15-inch loaded vented subwoofer enclosure as a simplified solution to add a competition-grade subwoofer system in your vehicle, without the guesswork involved in designing the system from scratch. This loaded enclosure features one of our powerful SDR-15 D2 1,200 watt max power 15-inch subwoofers, which arrives pre-loaded and wired up inside of the custom single 15" vented enclosure. The enclosure features a unique kerf port design, allowing for extreme levels of bass output. Furthermore, the enclosure is finished in premium grade black carpet for a sleek appearance and features the Skar Audio logo in white on the top surface of the box. The subwoofer comes pre-wired and loaded inside of the enclosure allowing for an easy and hassle free installation. The dual 2-ohm subwoofer is wired up inside of the enclosure so that the final impedance load is configured for 1-ohm at the terminals.
| Quick Facts |
|RMS Power Handling||600 Watts|
|Peak Power Handling||1,200 Watts|
|Enclosure Configuration||Single - 15"|
|Final Impedance Load||1 Ω|
This enclosure was engineered by Skar Audio specifically for the subwoofer that is loaded in it, ensuring perfect sound and compatibility. Every subwoofer is different, and when buying a loaded enclosure it is so critical to ensure that the subwoofer and enclosure are an ideal match, or you will lose sound quality and output. With this loaded subwoofer enclosure model, all of those concerns are eliminated, making it easier than ever to add powerful aftermarket bass to your vehicle.
|Enclosure Type||Single - 15" Vented|
|Fit Type||x1 SDR-15 D2 Subwoofer (Pre-Loaded)|
|Enclosure Style||Wedge Design|
|Port Type||Kerf Style (Maximum Bass)|
|Enclosure Feature||Double Baffle - Countersunk Design|
|Enclosure Finish||Premium Black Carpet|
|Wood Thickness & Material||5/8" MDF|
|Front Baffle Thickness||1.25"|
|Internal Air Space of Enclosure||4.50 ft3|
|Tuning Frequency of Enclosure||31 Hz|
|Push Terminal Location||Left Side of Enclosure|
|Final Impedance Load||1 Ω|
|RMS Power||600 Watts|
|Peak Power||1,200 Watts|
|Frequency Response||20 - 250 Hz|
|Sensitivity (SPL)||85.9 dB|
|Enclosure External Dimensions|
|Depth 1 (Bottom) Front to Back||22.75"|
|Depth 2 (Top) Front to Back||19.50"|
Upgraded from the dual 8 loaded enclosure. Powered with a Rp 1200.1 this thing shakes my whole car. Went from good bass to feel it in your chest bass.
I have a rxa f-1 and channel 1-2 are my door speakers and 3-4 is bridged to my subwoofer. at first i didn’t pay attention and ran the woofer at 1 ohm how the sub came. My amp would over heat after 20 minutes and i wasn’t impressed. I then took the subwoofer out and wired it for 4 ohm and put it back in and it was day and night. Sound quality was better 4 ohm maybe because that’s the amp i have or what not really educated on audio. I wish i could order the subwoofer in 4 ohm wire configuration instead of only 1 ohm.
Recently I purchased the SDR 15in Sub and Box Combo from Skar Audio and I’m truly amazed on the sound quality of this package for the price ! I’ve owned several other SKAR products and choose to stay loyal to them because of their quality product. SKAR Audio is my car audio Go To Brand !
I can’t complain at all. I paired it with a Skar RP-800.1D and this sub definitely hits hard and loud. Very satisfied.
This thing whams!! First speaker purchase with Skar Audio and I am completely satisfied. Had other 15's in the past and this is the best one I've owned for the price. You can tell it's not some cheap material, seems very high quality. I can't really find any negatives about this package. If tuned right with your amp you have some of the clearest and deepest bass around for a 15. I highly reccomend this speaker/enclosure package if you have a SUV or a van, only because of the size of the box. You will not be disappointed. I've been recommending Skar to anyone looking to buy any aftermarket audio system. Will definately be purchasing more Skar items in the future!
