Description
Description
The Skar Audio DDX-15 D2 is a competition grade, 15-inch, dual 2-ohm, car subwoofer. The DDX line-up was engineered by Skar Audio to be an SPL grade woofer that could also be utilized in daily system applications, allowing non-competitors to use the same subwoofers as those competing in the lanes. Every component used in the design of these woofers is of the highest quality for reliability and increased performance.
Conservatively rated at a 1,500 watts peak power and 1,000 watts RMS power, this subwoofer was engineered to be extremely loud. Featuring a massive double stack motor (202 oz), 2.5" pure copper high temperature voice coil, and a competition grade pressed paper cone stitched to the high roll foam surround, the woofer comes built ready to handle serious amounts power. Dual 2-ohm voice coil configuration.
Specifications
- Skar Audio DDX-15 D2 - 15" Component Car Subwoofer
- Dual 2 Ohm Voice Coil Configuration
- Peak Power: 1,500 Watts
- RMS Power: 1,000 Watts
- Competition Grade Pressed Paper Cone
- Stitched High Roll Foam Surround
- Advanced Air Flow Cooling System
- 2.5" High Temperature Copper Voice Coil
- Motor Weight: 202 oz
- Frequency Response: 30 - 400 Hz
- Sensitivity: 90.6 dB
- Fs: 41.0 Hz
- Re: 3.9 Ohms
- Qms: 4.2
- Qes: 0.44
- Qts: 0.39
- Nref: .72 %
- Cms: 0.05 mm/N
- Bl: 26.3 n/a
- Vas: 46.7 L
- Mms: 293 gr
- Sd: 804 cm^2
- Xmax: 15 mm
Enclosure Specifications
- Sealed Volume: 2.75~3.00 ft^3
- Ported Volume: 3.50~4.00 ft^3
- Port Area: 64.75 sq. in.
- Port Length: 25"
- Tuning Frequency: 36 Hz
- Mounting Depth: 7.83"
- Cut-Out Diameter: 13.97"
- Magnet Diameter: 7.72"
- Subwoofer Displacement: 0.17 ft^3
- Enclosure specifications do not include subwoofer, bracing, and port displacement
Description
The Skar Audio DDX-15 D4 is a competition grade, 15-inch, dual 4-ohm, car subwoofer. The DDX line-up was engineered by Skar Audio to be an SPL grade woofer that could also be utilized in daily system applications, allowing non-competitors to use the same subwoofers as those competing in the lanes. Every component used in the design of these woofers is of the highest quality for reliability and increased performance.
Conservatively rated at a 1,500 watts peak power and 1,000 watts RMS power, this subwoofer was engineered to be extremely loud. Featuring a massive double stack motor (202 oz), 2.5" pure copper high temperature voice coil, and a competition grade pressed paper cone stitched to the high roll foam surround, the woofer comes built ready to handle serious amounts power. Dual 4-ohm voice coil configuration.
Specifications
- Skar Audio DDX-15 D4 - 15" Component Car Subwoofer
- Dual 4 Ohm Voice Coil Configuration
- Peak Power: 1,500 Watts
- RMS Power: 1,000 Watts
- Competition Grade Pressed Paper Cone
- Stitched High Roll Foam Surround
- Advanced Air Flow Cooling System
- 2.5" High Temperature Copper Voice Coil
- Motor Weight: 202 oz
- Frequency Response: 30 - 400 Hz
- Sensitivity: 90.0 dB
- Fs: 41.6 Hz
- Re: 6.8 Ohms
- Qms: 4.3
- Qes: 0.50
- Qts: 0.45
- Nref: .65 %
- Cms: 0.05 mm/N
- Bl: 32.3 n/a
- Vas: 47.7 L
- Mms: 281 gr
- Sd: 804 cm^2
- Xmax: 15 mm
Enclosure Specifications
- Sealed Volume: 2.75~3.00 ft^3
- Ported Volume: 3.50~4.00 ft^3
- Port Area: 64.75 sq. in.
- Port Length: 25"
- Tuning Frequency: 36 Hz
- Mounting Depth: 7.83"
- Cut-Out Diameter: 13.97"
- Magnet Diameter: 7.72"
- Subwoofer Displacement: 0.17 ft^3
- Enclosure specifications do not include subwoofer, bracing, and port displacement
