Description
Description
The Skar Audio EVL-65 D2 subwoofer was designed to be the most responsive, powerful, and efficient 6.5 inch subwoofer on the market. Don't be fooled by the size, the EVL-65 is one monster of a subwoofer, featuring a 2" pure copper voice coil, and a powerful 39 Oz single slug ferrite motor. The small size of this driver allows it to be very versatile, and can be used in a variety of applications where adding a woofer might not otherwise be possible. Conservatively rated at 200 watts RMS Power, and 400 watts max power. Dual 2-ohm voice coil. Sensitivity: 83.1 dB, Fs: 61 Hz, Xmax: 6.25mm one-way.
Specifications
- Skar Audio EVL-65 D2 - 6.5" Component Car Subwoofer
- Dual 2 Ohm Voice Coil Configuration
- Peak Power: 400 Watts
- RMS Power: 200 Watts
- Skar Audio Magnet Boot Cover for Enhanced Appearance
- 2" High Temperature Copper Voice Coil
- Motor Weight: 39 oz
- Sensitivity: 83.1 dB
- Fs: 61 Hz
- Re: 1.8 Ohms
- Qms: 4.48
- Qes: 0.43
- Qts: 0.39
- Rms: 4.57 Kg/s
- Cms: 0.126 mm/N
- Bl: 13 n/a
- Vas: 2.3 Liters
- Xmax: 6.25 mm
Photos
Enclosure Specifications
- Sealed Volume: 0.25 ft^3
- Ported Volume: 0.60 ft^3
- Port Area: 8.5 sq.in.
- Port Length: 18"
- Tuning Frequency: 40 Hz
- Displacement: 0.019 cu ft
- Mounting Depth: 3.561"
- Cut-Out Diameter: 5.826"
- Outside Dimension: 6.854"
- Magnet Diameter: 5.526"
- Enclosure specifications do not include subwoofer, bracing, and port displacement
Description
The Skar Audio EVL-65 D4 subwoofer was designed to be the most responsive, powerful, and efficient 6.5-inch subwoofers on the market. Don't be fooled by the size, the EVL-65 is one monster of a subwoofer, featuring a 2" pure copper voice coil, and a powerful 39 Oz single slug ferrite motor. The small size of this driver allows it to be very versatile, and can be used in a variety of applications where adding a woofer might not otherwise be possible. Conservatively rated at 200 watts RMS Power, and 400 watts max power. Dual 4-ohm voice coil. Sensitivity: 82.8 dB, Fs: 64 Hz, Xmax: 6.25mm one-way.
Specifications
- Skar Audio EVL-65 D4 - 6.5" Component Car Subwoofer
- Dual 4 Ohm Voice Coil Configuration
- Peak Power: 400 Watts
- RMS Power: 200 Watts
- Skar Audio Magnet Boot Cover for Enhanced Appearance
- 2" High Temperature Copper Voice Coil
- Motor Weight: 39 oz
- Sensitivity: 82.8 dB
- Fs: 64 Hz
- Re: 3.6 Ohms
- Qms: 4.6
- Qes: 0.60
- Qts: 0.53
- Rms: 4.
34 kg/s - Cms: 0.126 mm/N
- Bl: 15.4 n/a
- Vas: 2.2 cm^3
- Xmax: 6.25 mm
Photos
Enclosure Specifications
- Sealed Volume: 0.25 ft^3
- Ported Volume: 0.60 ft^3
- Port Area: 8.5 sq.in.
- Port Length: 18"
- Tuning Frequency: 40 Hz
- Displacement: 0.019 cu ft
- Mounting Depth: 3.561"
- Cut-Out Diameter: 5.826"
- Outside Dimension: 6.854"
- Magnet Diameter: 5.526"
- Enclosure specifications do not include subwoofer, bracing, and port displacement
EVL-65 | 6.5" 400 Watt Max Power Car Subwoofer
I have them 2 of them on a skm5001 and all I can say is wow.. The box is tuned to ~40hz each side is ~0.60 cubic feet. Also everyone does Rap vids so I had to do a rock one, that's about 1/2 volume. I did this vid almost as soon as I installed them and didn't want to run them to hard yet.
So far perfect thank you
The easy stuff is all good, but I am still gathering components and pieces for my harley saddlebag system so cannot accurately rate the subs yet, but once it's up and running then I will...
I recently bought 3 of the Skar audio EVL 6.5. The only negative thing I have to say is wiring them due to the terminals is a pain in the ass. Bought the DVC 2 ohm and wired them in series (after bridging the subs) and running at 1 ohm. I have a Audiopipe APMI-1300 series amp powering them at around 750-800 watts and they hit hard. I would have never thought 3 6.5” subs would be so great but I’m loving my purchase. Friend and I built the box and it’s tuned for 35 hz. All around I’m loving the Skar subs. 9/10 would recommend. Only reason it’s not 10/10 is due to the terminals being a bitch to get to and wire.
In the video I posted the first few seconds I was turning the head unit up to 15 which is plenty loud. It goes up to 40. I was also using my sons iPad connected to Bluetooth playing,
“Got 160s by Aaron Bau” it’s a big playlist and it has songs playing anything from 24 hz and up. I chose the song oxycotton cause it hits hard. Video honestly doesn’t do it justice.
Outstanding purchase.
