MPN | SVR-12 D2 |
UPC | 810028810655 |
Size | 12" |
Type | Car Subwoofer |
Cone Type | Competition Grade Pressed Paper Cone |
RMS Power | 800 Watts |
Peak Power | 1600 Watts |
Surround Type | Stitched High Roll Foam Surround |
Voice Coil Size | 2.60" |
Magnet Slug Count | Double |
Voice Coil Layers | 4 |
Voice Coil Material | Copper (Pure Copper) |
Voice Coil Impedance | Dual 2 Ω |
Bl | 19.77 n/a |
Fs | 36 Hz |
Re | Dual 2 Ω |
Sd | 530.9 cm2 |
Cms | 0.073 mm/N |
Mms | 255.6 gr |
Qes | 0.56 |
Qms | 7.05 |
Qts | 0.52 |
Vas | 29.2 L |
Nref | 0.245% |
Xmax | 15 mm (one-way) |
Sensitvity | 86.1 dB |
Enclosure Disclaimer | Enclosure recommendations above do not include subwoofer, bracing, and port displacement |
Recommended Port Area | 21.875 in² |
Recommended Ported Volume | 1.75 - 2.00 ft³ |
Recommended Sealed Volume | 1.00 - 1.35 ft³ |
Recommended Tuning Frequency | 34 Hz |
Total Height | 7.65" |
Mounting Depth | 6.68" |
Magnet Diameter | 6.70" |
Cut-out Diameter | 11.20" |
Outside Diameter | 12.68" |
119.99 11999
