SDR-10 | 1,200 Watt Max Power Car Subwoofer

  • SDR-10 | 1,200 Watt Max Power Car Subwoofer

SDR-10 | 1,200 Watt Max Power Car Subwoofer


* Financing through our Partner, Bread

Description

Description

The Skar Audio SDR series was engineered to dish out reliable, hard hitting, and low spectrum sound. Featuring a high flux ferrite motor, this woofer will provide extreme power handling for extended periods of time. The SDR series will quickly become a customer favorite, as it's perfect for people just entering the world of car audio all the way up to seasoned pros.



The SDR series features a 2.5” high temperature 4-layer high temperature copper voice coil that is attached to our Skar Audio signature red spider. The surround on the SDR series is a high roll foam surround which allows the woofer to produce riveting low end bass response. The SDR series has a max power rating of 1,200 watts and a RMS power rating of 600 watts.

Specifications

  • Skar Audio SDR-10 D2 - 10" Component Car Subwoofer
  • Dual 2 Ohm Voice Coil Configuration
  • Peak Power: 1200 Watts
  • RMS Power: 600 Watts
  • Competition Grade Pressed Paper Cone
  • Stitched High Roll Foam Surround
  • Advanced Air Flow Cooling System
  • 2.5" High Temperature Copper Voice Coil
  • Motor Weight: 97 oz
  • Frequency Response: 39 - 300 Hz
  • Sensitivity: 82 dB
  • Fs: 39 Hz
  • Re: 1.9 Ohms
  • Qms: 6.75
  • Nref: 0.116%
  • Qes: 0.63
  • Qts: 0.58
  • Cms: 0.078 mm/N
  • Bl: 18.41 n/a
  • Vas: 10.85 L
  • Mms: 213.9 gr
  • Sd: 298.65 cm²
  • Xmax: 13.5 mm

Enclosure Specifications

  • Sealed Volume: .95 ft³
  • Ported Volume: 1.65 ft³
  • Port Area: 21 sq in
  • Port Length: 18"
  • Tuning Frequency: 39Hz
  • Mounting Depth: 6.08"
  • Total Height:"
  • Outside Diameter: 10.33"
  • Cut-Out Diameter: 8.93"
  • Magnet Diameter: 6.00"
  • Subwoofer Displacement: .041 ft³
  • Enclosure specifications do not include subwoofer, bracing, and port displacement

Description

The Skar Audio SDR series was engineered to dish out reliable, hard hitting, and low spectrum sound. Featuring a high flux ferrite motor, this woofer will provide extreme power handling for extended periods of time. The SDR series will quickly become a customer favorite, as it's perfect for people just entering the world of car audio all the way up to seasoned pros.



The SDR series features a 2.5” high temperature 4-layer high temperature copper voice coil that is attached to our Skar Audio signature red spider. The surround on the SDR series is a high roll foam surround which allows the woofer to produce riveting low end bass response. The SDR series has a max power rating of 1,200 watts and a RMS power rating of 600 watts.

Specifications

  • Skar Audio SDR-10 D4 - 10" Component Car Subwoofer
  • Dual 4 Ohm Voice Coil Configuration
  • Peak Power: 1200 Watts
  • RMS Power: 600 Watts
  • Competition Grade Pressed Paper Cone
  • Stitched High Roll Foam Surround
  • Advanced Air Flow Cooling System
  • 2.5" High Temperature Copper Voice Coil
  • Motor Weight: 97 oz
  • Frequency Response: 39 - 300 Hz
  • Sensitivity: 82.5 dB
  • Fs: 39 Hz
  • Re: 3.2 Ohms
  • Qms: 6.08
  • Nref: 0.126%
  • Qes: 0.68
  • Qts: 0.61
  • Nref: %
  • Cms: 0.079 mm/N
  • Bl: 10.9 n/a
  • Vas: 11 L
  • Mms: 188.75 gr
  • Sd: 298.65 cm²
  • Xmax: 13.5 mm

Enclosure Specifications

  • Sealed Volume: .95 ft³
  • Ported Volume: 1.65ft ft³
  • Port Area:  21 in²
  • Port Length: 18"
  • Tuning Frequency: 39Hz
  • Mounting Depth: 6.08"
  • Total Height: "
  • Outside Diameter: 10.33"
  • Cut-Out Diameter: 8.93"
  • Magnet Diameter: 6.00"
  • Subwoofer Displacement: .041 ft³
  • Enclosure specifications do not include subwoofer, bracing, and port displacement
