SDR-18 | 1,200 Watt Max Power Car Subwoofer

  • skar-audio-sdr-18-inch-dual-voice-coil-subwoofer-1200-watts-max-color

SDR-18 | 1,200 Watt Max Power Car Subwoofer


* Financing through our Partner, Bread

Description

Description

The Skar Audio SDR-18 D2 was designed to offer the ultra low end bass frequency response only capable of being produced by a larger subwoofer of this size. Featuring a conservative rating of 1,200 watts max power, this 18 inch car subwoofer does just that, thanks to it's high temperature 2.5-inch copper voice coil and high flux ferrite motor.



When looking for a subwoofer that delivers low end frequencies with authority, look no further. This is the perfect solution for a 600-1200 watt daily driver that can handle whatever is thrown at it, offering unmatched reliability and sound quality. Featuring a sleek and attractive red spider system, paired with it's competition grade paper cone and high roll foam surround, this subwoofer is going to impress the listener every time it is playing.

Specifications

  • Skar Audio SDR-18 D2 - 18" Component Car Subwoofer
  • Dual 2 Ohm Voice Coil Configuration
  • Peak Power: 1200 Watts
  • RMS Power: 600 Watts
  • Competition Grade Pressed Paper Cone
  • Stitched High Roll Foam Surround
  • Advanced Air Flow Cooling System
  • 2.5" High Temperature Copper Voice Coil
  • Motor Weight: 97 oz
  • Frequency Response: 24 - 300 Hz
  • Sensitivity: 87.3 dB
  • Fs: 24 Hz
  • Re: 1.9 Ohms
  • Qms: 4.68
  • Nref: 0.33%
  • Qes: 0.8
  • Qts: 0.69
  • Cms: 0.107 mm/N
  • Bl: 17.11 n/a
  • Vas: 206 L
  • Mms: 413 gr
  • Sd: 1164.1 cm²
  • Xmax: 13.5 mm one-way

Enclosure Specifications

  • Sealed Volume: 2.75 ft³
  • Ported Volume: 4.60 ft³
  • Port Area: 64.75 in²
  • Port Length: 29.75"
  • Tuning Frequency: 32 Hz
  • Mounting Depth: 8.00"
  • Total Height: 9.325"
  • Outside Diameter: 18.275"
  • Cut-Out Diameter: 16.765"
  • Magnet Diameter: 6.065"
  • Subwoofer Displacement: 0.19 ft³
  • Enclosure specifications do not include subwoofer, bracing, and port displacement

Description

The Skar Audio SDR-18 D4 was designed to offer the ultra low end bass frequency response only capable of being produced by a larger subwoofer of this size. Featuring a conservative rating of 1,200 watts max power, this 18 inch car subwoofer does just that, thanks to it's high temperature 2.5-inch copper voice coil and high flux ferrite motor.



When looking for a subwoofer that delivers low end frequencies with authority, look no further. This is the perfect solution for a 600-1200 watt daily driver that can handle whatever is thrown at it, offering unmatched reliability and sound quality. Featuring a sleek and attractive red spider system, paired with it's competition grade paper cone and high roll foam surround, this subwoofer is going to impress the listener every time it is playing.

Specifications

  • Skar Audio SDR-18 D4 - 18" Component Car Subwoofer
  • Dual 4 Ohm Voice Coil Configuration
  • Peak Power: 1200 Watts
  • RMS Power: 600 Watts
  • Competition Grade Pressed Paper Cone
  • Stitched High Roll Foam Surround
  • Advanced Air Flow Cooling System
  • 2.5" High Temperature Copper Voice Coil
  • Motor Weight: 97 oz
  • Frequency Response: 24 - 300 Hz
  • Sensitivity: 86.7 dB
  • Fs: 24 Hz
  • Re: 3.2 Ohms
  • Qms: 4.99
  • Nref: 0.29%
  • Qes: 0.59
  • Qts: 0.76
  • Cms: 0.104 mm/N
  • Bl: 10.69 n/a
  • Vas: 200 L
  • Mms: 428.8 gr
  • Sd: 1164.1 cm²
  • Xmax: 13.5 mm one-way

Enclosure Specifications

  • Sealed Volume: 2.75 ft³
  • Ported Volume: 4.50 ft ft³
  • Port Area: 64.75 in²
  • Port Length: 29.75"
  • Tuning Frequency: 32 Hz
  • Mounting Depth: 8.00"
  • Total Height: 9.325"
  • Outside Diameter: 18.275"
  • Cut-Out Diameter: 16.765"
  • Magnet Diameter: 6.065"
  • Subwoofer Displacement: 0.19 ft³
  • Enclosure specifications do not include subwoofer, bracing, and port displacement
