VD-12 | 12" 800 Watt Max Power Car Subwoofer (Shallow Mount)

  • VD-12 | 12

VD-12 | 12" 800 Watt Max Power Car Subwoofer (Shallow Mount)

Description

Description

The Skar Audio VD-12 D2 is a 12-inch, dual 2-ohm, shallow mount car subwoofer. This woofer was engineered to sound great and handle ample amounts of power all while maintaining a shallow foot print, which allows them to be very versatile in use. This driver utilizes a high temperature 2-inch voice coil, which in conjunction with it's powerful, yet low profile single stack ferrite magnet, allow it to perform with dominance. The VD series make for a great under seat subwoofer or for use in applications where mounting depth is limited. 12-inch car subwoofer. Dual 2 ohm voice coil. Max power: 800 Watts. RMS Power: 500 Watts. Fs: 35.0 Hz, Spl: 86.7 dB. Mounting Depth: 4.92"

Specifications

  • Skar Audio VD-12 D2 - 12" Shallow Mount Car Subwoofer
  • Dual 2 Ohm Voice Coil Configuration
  • Peak Power: 800 Watts
  • RMS Power: 500 Watts
  • Pressed Paper Cone
  • High Roll Foam Surround
  • 2" High Temperature Copper Voice Coil
  • Motor Weight: 66 oz
  • Frequency Response: 35 - 300 Hz
  • Sensitivity: 86.7 dB
  • Fs: 35.3 Hz
  • Re: 3.9 Ohms
  • Qms: 4.42
  • Qes: 0.62
  • Qts: 0.55
  • Nref: 0.30 %
  • Cms: 0.12 mm/N
  • Bl: 15.6 n/a
  • Vas: 43.5 L
  • Xmax: 11 mm

Enclosure Specifications

  • Sealed Volume: 1.00 ft^3
  • Ported Volume: 1.75 ft^3
  • Port Area: 25 sq.in.
  • Port Length: 23"
  • Tuning Frequency: 36 Hz
  • Mounting Depth: 4.92"
  • Cut-Out Diameter: 11.3"
  • Magnet Diameter: 6.3"
  • Subwoofer Displacement: 0.10 ft^3
  • Enclosure specifications do not include subwoofer, bracing, and port displacement

Description

The Skar Audio VD-12 D4 is a 12-inch, dual 4-ohm, shallow mount car subwoofer. This woofer was engineered to sound great and handle ample amounts of power all while maintaining a shallow foot print, which allows them to be very versatile in use. This driver utilizes a high temperature 2-inch voice coil, which in conjunction with it's powerful, yet low profile single stack ferrite magnet, allow it to perform with dominance. The VD series make for a great under seat subwoofer or for use in applications where mounting depth is limited. 12-inch car subwoofer. Dual 4-ohm voice coil. Max power: 800 Watts. RMS Power: 500 Watts. Fs: 36.0 Hz, Spl: 86.7 dB. Mounting Depth: 4.92"

Specifications

  • Skar Audio VD-12 D4 - 12" Shallow Mount Car Subwoofer
  • Dual 4 Ohm Voice Coil Configuration
  • Peak Power: 800 Watts
  • RMS Power: 500 Watts
  • Pressed Paper Cone
  • High Roll Foam Surround
  • 2" High Temperature Copper Voice Coil
  • Motor Weight: 66 oz
  • Frequency Response: 35 - 300 Hz
  • Sensitivity: 85.9 dB
  • Fs: 36.6 Hz
  • Re: 7.1 Ohms
  • Qms: 4.20
  • Qes: 0.70
  • Qts: 0.60
  • Nref: 0.28 %
  • Cms: 0.12 mm/N
  • Bl: 18.2 n/a
  • Vas: 44.3 L
  • Xmax: 11 mm

Enclosure Specifications

  • Sealed Volume: 1.00 ft^3
  • Ported Volume: 1.75 ft^3
  • Port Area: 25 sq.in.
  • Port Length: 23"
  • Tuning Frequency: 36 Hz
  • Mounting Depth: 4.92"
  • Cut-Out Diameter: 11.3"
  • Magnet Diameter: 6.3"
  • Subwoofer Displacement: 0.10 ft^3
  • Enclosure specifications do not include subwoofer, bracing, and port displacement

Customer Reviews

Based on 14 reviews
100%
(14)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
M
M.L.
Good subwoofer

Good quality subwoofer. Not a lot of bass but it’s not meant for a lot.

N
N.
Looking for some answers.

Have 2 12s downfire in Sierra xtra cab on rp1500 and for some reason mine sound like shit nowhere compared to my Memphis mclass 12s on a Memphis 1000???? Sealed box at .95 ft subs keep seizing at loud vol. gain set properly, I know what I’m doing so it’s not settings I’m just curious as to why I’m getting excursion with no sound and why they keep popping and seizing

S
S.R.

VD-12 | 12" 800 Watt Max Power Car Subwoofer (Shallow Mount)

A
A.
So far so good!

I am still in the break in stage. Everyday when I start up my vehicle and turn the volume up a notch or two the VD 12 seems like it hit harder and harder each passing day. I love the excursion that this sub have. I want another one really soon.

R
R.W.
Damn!

Sorry to start off like that, but damn these things are great! Got 2 VD-12's and a LP-1000w amp, a $35 wiring kit and built my own sealed box for a 03 Silverado extended cab (underseat box, that's why I got shallows). And these things hit hard! I though about getting some kickers at first because the price was double, I thought, double price double quality but noooooo. I have a friend who has some kickers and I'm just as loud for half the price! Thanks skar, 10/10 would recommend.
