Description
Description
Skar Audio created this premium complete EVL-2X12D4 bass package to make it easier than ever to add low-frequency, head-turning bass to your vehicle. This package features two, 12-inch, dual 4-ohm, Skar Audio EVL series subwoofers, which are pre-loaded and wired up inside a rugged dual 12-inch wedge-style ported enclosure. The enclosure features our advanced port and split chamber woofer design, allowing for extreme levels of bass output, while reducing distortion. Due to the weight of the massive EVL motor, we built this enclosure with extensive internal bracing, ensuring structural integrity and reliability. Furthermore, this custom enclosure is covered in premium grade black carpeting, providing a sleek appearance that allows the enclosure to look as good as it sounds. We also include the perfect amplifier in this package to power your new subwoofer with the Skar Audio RP-2000.1D, which comes with a premium 1/0 gauge amplifier wiring kit to make installing the amplifier hassle free.
We take the guess work out of pairing the components of your system up, and make it easy to get the bass you've always wanted in your ride. The subwoofers come pre-wired and loaded inside of the enclosure allowing for an easy and hassle free installation. The dual 4 ohm subwoofers are wired up inside of the enclosure so that the final impedance load is configured for 1-ohm at the terminals (one terminal cup). Peak Power: 5,000 Watts, RMS Power: 2,500 Watts
The dual 4-ohm subwoofers included in this package are pre-configured and wired up inside of the subwoofer enclosure at a 1-ohm final load to ensure an easy and hassle free installation.
Subwoofer Specifications
- Includes (2) Subwoofers Pre-Loaded Into Subwoofer Enclosure
- Skar Audio EVL-12 D4 12" Competition Car Subwoofer
- Dual 4 Ohm
- RMS Power: 2,500 Watts
- Peak Power: 5,000 Watts
- Voice Coil Size: 3"
- 4 Layer Black Aluminum CCAW Voice Coil
- Frequency Response: 25 Hz - 250 Hz
- High Roll Foam Surround
- Sensitivity: 85.3 dB
- Fs: 32.6 Hz
- Re: 3.8 Ohms
- Qms: 5.00
- Qes: 0.56
- Qts: 0.46
- Mms: 256.3 g
- Cms: 0.059 mm/N
- Bl: 12.8 n/a
- Vas: 18.2 L
- Sd: 471.4 cm²
- Xmax: 23.5mm (one-way)
Amplifier Specifications
- Skar Audio RP-2000.1D Class D Monoblock Car Subwoofer Amplifier
- 1 Ohm Stable Class D Monoblock Subwoofer Amplifier
- 4 Way Protection Circuitry: Thermal, Voltage, Speaker, DC
- RMS Power at 1 Ohms: 2,000 Watts x 1 Channel (14.4v)
- RMS Power at 2 Ohm: 1,400 Watts x 1 Channel (14.4v)
- RMS Power at 4 Ohms: 800 Watts x 1 Channel (14.4v)
- MOSFET Power Supply
- Soft Turn on Circuit
- Frequency Response: 20 Hz ~ 250 Hz
- Signal to Noise Ratio: 85dB
- Damping Factor: 150<
- Low Pass Filter (Variable): 50Hz~220hz
- Subsonic Filter: Off~50Hz
- Remote Bass Knob & Wire Included
- 1/0 Gauge Power and Ground Terminals
- Working Voltage: 8.5V-14.4V
- Fuse Rating: 200 Amp
- Dimensions: 17" (Length) x 6.3" (Width) x 2.2" (Height)
Amp Kit Specifications
- Skar Audio Model: SKAR0ANL-CCA
- 1/0 Gauge Complete Amplifier Installation Kit
- Everything You Need to Install & Wire Up Your Amplifier
- Great for Amplifiers up to 2,000 Watts
- 17 ft. of 1/0 Gauge CCA Matte Blue Ultra Flexible Power Cable
- 3 ft. of 1/0 Gauge CCA Matte Brown Ultra Flexible Ground Cable
- 17 ft. of Blue Remote Turn-on Wire
- 20 ft. of 12-Gauge Premium Multi-stranded Speaker Wire
- 17 ft RCA 2-Channel Blue Twisted Pair Shielded Interconnect Cable
- High Current Waterproof ANL Fuse Holder
- 200 Amp ANL Fuse Included
- Ring Terminals
- Ground Terminals
- Vinyl Cable Ties
Enclosure Specifications
- Dual 12-Inch Ported Subwoofer Enclosure
- Wedge Style Design
- 2-Hole 12" Vented Carpeted box
- Wood Thickness & Material: 5/8" MDF
- Front Baffle Thickness & Material: 1.25" MDF
- Industrial-Grade Black Colored Carpet
- Premium Spring-loaded Terminals
- Air Space: 2.0 Cubic Feet (per sub)
- Tuning: 32 Hz
- Height: 15.75"
- Width: 35.5"
- Depth #1: 20.5"
- Depth #2: 17.0"
- Depth Measurements Include the Subwoofers
- Port Dimensions: 2.36" W x 14.57" H x 24.21" L
I have a 2004 ion coupe and they are super loud in the car. It sucks that I had to take a day off work to sign for the package , but I am impressed with the build quality and sound quality.
Only bad thing!! I blew my back glass out of my truck. My amp was below half, as I was trying to break in the subs properly. I just ordered all skar mids and tweeters to replace my entire speaker system in my tundra. Can’t be more pleased with mine bravo skate audio!!!
Great set up but have to turn amp gain 1/2 way to get any sound. Amp gets pretty hot as well . Anything past that amp goes into protection. Sub box is massive 120lbs with subs so you need room but will fit behind 3rd row seating. Also need additional power source for amp as I added another battery. All around great deal but can’t wait too get a 2nd amp, one for each sub. I also purchased the sk-T tweeters they are awesome, I also have the skar super tweeters and both pair are amplified but the sk-t tweeters put out just as much as the super tweeters. I would recommend this product.
Put these in my 68 Fleetwood. Trunk is huge but these combo hits so hard. LOVE LOVE LOVE how they sound. Next, all interior skar audio.
These are the best subs I've ever owned. Put in my 2019 challenger scat pack and I'm the police have all eyes on me baby. No lights needed on car just skar evl king Kong in trunk.
